Nominal Hose I.D.		Nominal Hose O.D.	Working Pressure		Burst Pressure
Inch	mm	mm	Bar	psi	Bar	psi
1/2	12.7	21.0	10	150	30	450
5/8	15.9	25.0	10	150	30	450
3/4	19.0	29.0	10	150	30	450
7/8	22.2	31.0	10	150	30	450
1	25.4	35.0	10	150	30	450
1-1/8	28.6	38.0	10	150	30	450
1-3/16	30.0	40.0	10	150	30	450
1-1/4	31.8	42.0	10	150	30	450
1-5/16	33.4	43.0	10	150	30	450
1-3/8	35.0	45.0	10	150	30	450
1-1/2	38.1	48.0	10	150	30	450
1-9/16	40.0	50.0	10	150	30	450
1-5/8	41.3	52.0	10	150	30	450
1-3/4	44.5	56.0	10	150	30	450
1-7/8	47.8	60.0	10	150	30	450
2	50.8	63.0	10	150	30	450
2-1/8	54.0	66.0	10	150	30	450
2-1/4	57.0	69.0	10	150	30	450
2-3/8	60.5	74.0	10	150	30	450
2-1/2	63.5	77.0	10	150	30	450
2-5/8	66.0	80.0	10	150	30	450
2-3/4	70.0	84.0	10	150	30	450
2-7/8	73.3	88.0	10	150	30	450
3	76.2	90.0	10	150	30	450
3-1/8	80.0	95.0	10	150	30	450
3-1/2	88.9	104.0	10	150	30	450
4	101.6	118.0	10	150	30	450
4-1/2	114.3	130.0	6	90	18	270
5	127.0	143.0	6	90	18	270
6	152.0	170.0	6	90	18	270
6-5/8	168.0	186.0	6	90	18	270
8	203.2	223.0	6	90	18	270
8-5/8	219.0	237.0	6	90	18	270
10	254.0	278.0	6	90	18	270
12	304.0	328.0	6	90	18	270

Working Temperature: -20°C to +80°C
Appliction : Suitable for marine exhaust / tank, truck and plant operation, withstand aromatic contents up to 55%.
