Nominal Hose I.D.		Nominal Hose O.D.	Working Pressure		Burst Pressure
Inch	mm	mm	Bar	psi	Bar	psi
1/4	6.3	15.8	13	195	52	780
5/16	8.0	17.5	13	195	52	780
3/8	9.5	20.0	10	150	40	600
1/2	12.7	24.0	10	150	40	600
5/8	15.8	27.0	10	150	40	600
3/4	19.0	30.0	10	150	40	600
1	25.4	36.0	8	120	32	480

Working Temperature: -25°C to +110°C
Appliction : Suitable for usage in fuel hose, resistant to gasoline, diesel and alcohol
                     enhanced fuels. Low gas permeability allowed this hose for other gas tight application.

Nominal Hose I.D.		Nominal Hose O.D.	Working Pressure		Burst Pressure
Inch	mm	mm	Bar	psi	Bar	psi
1/4	6.3	12.7	3	50	12	200
5/16	8.0	14.3	3	50	12	200
3/8	9.5	15.8	3	50	12	200
5/8	15.8	23.8	3	50	12	200

Working Temperature: -25°C to +110°C
Appliction : Designed for usage in non-enclosed engine compartments where
                    resistant to gasoline, diesel and alcohol enhanced fuels is necessary. Low gas
                    permeability allowed this hose in few gas conveying application also. allowed the hose for other gas tight application.
